We design power supplies:
switch mode, SMPS:
- off line
- flyback, forward, half bridge, and others
- agency compliant
- multi output
- low ouput noise
- wide input range
- DC to DC
- battery operated DC to DC
linear
- continuous output range from positive to negative
- sink and source capability
high voltage, HVPS
- high stability
- low output ripples
- low output impedance
- bias circuits for:
- ion detectors
- radiation detectors
- electron multipliers
- power circuits in vacuum
battery backup
- seamless switching
- short term backup with super capacitors
battery charger
- switch mode
- solar panel regulator
- battery monitoring
We design magnetics and PCB:
- transformers for the switch mode power supplies
- common mode inductors for the forward converters.
- inductors for the resonant tank as well as other magnetics.
- we provide PCB design, printed circuit board, for all our designs
We provide operating test results:
- line regulation
- load regulation
- cross regulation
- short term and long term stability
- thermal stability,
We verify:
- control loop stability
- behaviour with dynamic load
- start up ramp
- effects of shorted output
System level
we help with
System power distribution
System grounding
EMI / RFI reduction
improvement of radiated immunity
We do pre production tests:
- DVT test results
- MTBF
- agency precompliance
Test fixtures, custom loads etc can also be provided.
Specify your power supply and Electronic Structures will design it.
The advantages and benefits of outsourcing design to E.S.:
Immediate access to talented and experienced engineers.
Minimum entry delay of the product to the market resulting in maximum revenue by launching the product ahead of the competition.
Eliminates need to add permanent staff to design a new product.
